Pulse function full details:

• iPOWER X Pulse function design for apple mobile phone repair industry, simulate power on that can be used with bare motherboards without battery connected
• The mobile phone battery simulator ports are hardware limited to 4.3V to protect against accidental voltage settings that might damage the device
• Current limited continuously from 0.1 -3A so that the user can track down short circuit in devices by monitoring board temperature
• With reverse voltage protection in case of wrong connections
• Can test related function purpose for connected device when "Auto pulse function" enable

How is working:

• Apply output voltage and current settings by press "Power" button (Black rotary button) to enable output power
• Put connected apple mobile bare board data cable into iPOWER X Box USB port
• Press "On" button 1~2 seconds to power on the bare board

How is working with computer:

• Apply related settings option by press "Start" button to enable output power
• Put connected apple mobile bare boards data cable into iPOWER X Box USB port
• Press "Pulse" to power on the bare board
